ubuntu测试串口的方法：

测试新机器的串口硬件的是否正常，可借用以下程序测试串口是否正常运行，代码如下：

#include /*标准输入输出定义*/

#include

#include /*Unix标准函数定义*/

#include /**/

#include /**/

#include /*文件控制定义*/

#include /*PPSIX终端控制定义*/

#include /*错误号定义*/

#include

#include

#define FALSE 1

#define TRUE 0

char *recchr="We received:\"";

void print_usage();

int speed_arr[] = {

B921600, B460800, B230400, B115200, B57600, B38400, B19200,

B9600, B4800, B2400, B1200, B300,

};

int name_arr[] = {

921600, 460800, 230400, 115200, 57600, 38400, 19200,

9600, 4800, 2400, 1200, 300,

};

void set_speed(int fd, int speed)

{

int i;

int status;

struct termios Opt;

tcgetattr(fd, &Opt);

for ( i= 0; i < sizeof(speed_arr) / sizeof(int); i++) {

if (speed == name_arr[i]) {

tcflush(fd, TCIOFLUSH);

cfsetispeed(&Opt, speed_arr[i]);

cfsetospeed(&Opt, speed_arr[i]);

status = tcsetattr(fd, TCSANOW, &Opt);

if (status != 0)

perror("tcsetattr fd1");

return;

}

tcflush(fd,TCIOFLUSH);

}

if (i == 12){

printf(" Sorry, please set the correct baud rate!

");

print_usage(stderr, 1);

}

}

/*

*@brief 设置串口数据位，停止位和效验位

*@param fd 类型 int 打开的串口文件句柄*

*@param databits 类型 int 数据位 取值 为 7 或者8*

*@param stopbits 类型 int 停止位 取值为 1 或者2*

*@param parity 类型 int 效验类型 取值为N,E,O,,S

*/

int set_Parity(int fd,int databits,int stopbits,int parity)

{

struct termios options;

if ( tcgetattr( fd,&options) != 0) {

perror("SetupSerial 1");

return(FALSE);

}

options.c_cflag &= ~CSIZE ;

switch (databits) /*设置数据位数*/ {

case 7:

options.c_cflag |= CS7;

break;

case 8:

options.c_cflag |= CS8;

break;

default:

fprintf(stderr,"Unsupported data size
");

return (FALSE);

}

switch (parity) {

case 'n':

case 'N':

options.c_cflag &= ~PARENB; /* Clear parity enable */

options.c_iflag &= ~INPCK; /* Enable parity checking */

break;

case 'o':

case 'O':

options.c_cflag |= (PARODD | PARENB); /* 设置为奇效验*/

options.c_iflag |= INPCK; /* Disnable parity checking */

break;

case 'e':

case 'E':

options.c_cflag |= PARENB; /* Enable parity */

options.c_cflag &= ~PARODD; /* 转换为偶效验*/

options.c_iflag |= INPCK; /* Disnable parity checking */

break;

case 'S':

case 's': /*as no parity*/

options.c_cflag &= ~PARENB;

options.c_cflag &= ~CSTOPB;

break;

default:

fprintf(stderr,"Unsupported parity
");

return (FALSE);

}

/* 设置停止位*/

switch (stopbits) {

case 1:

options.c_cflag &= ~CSTOPB;

break;

case 2:

options.c_cflag |= CSTOPB;

break;

default:

fprintf(stderr,"Unsupported stop bits
");

return (FALSE);

}

/* Set input parity option */

if (parity != 'n')

options.c_iflag |= INPCK;

options.c_cc[VTIME] = 150; // 15 seconds

options.c_cc[VMIN] = 0;

options.c_lflag &= ~(ECHO | ICANON);

tcflush(fd,TCIFLUSH); /* Update the options and do it NOW */

if (tcsetattr(fd,TCSANOW,&options) != 0) {

perror("SetupSerial 3");

return (FALSE);

}

return (TRUE);

}

/**

*@breif 打开串口

*/

int OpenDev(char *Dev)

{

int fd = open( Dev, O_RDWR ); //| O_NOCTTY | O_NDELAY

if (-1 == fd) { /*设置数据位数*/

perror("Can't Open Serial Port");

return -1;

} else

return fd;

}

/* The name of this program */

const char * program_name;

/* Prints usage information for this program to STREAM (typically

* stdout or stderr), and exit the program with EXIT_CODE. Does not

* return.

*/

void print_usage (FILE *stream, int exit_code)

{

fprintf(stream, "Usage: %s option [ dev... ]
", program_name);

fprintf(stream,

" -h --help Display this usage information.
"

" -d --device The device ttyS[0-3] or ttySCMA[0-1]
"

" -b --baudrate Set the baud rate you can select
"

" [230400, 115200, 57600, 38400, 19200, 9600, 4800, 2400, 1200, 300]
"

" -s --string Write the device data
");

exit(exit_code);

}

/*

*@breif main()

*/

int main(int argc, char *argv[])

{

int fd, next_option, havearg = 0;

char *device;

int i=0,j=0;

int nread; /* Read the counts of data */

char buff[512]; /* Recvice data buffer */

pid_t pid;

char *xmit = "1234567890"; /* Default send data */

int speed ;

const char *const short_options = "hd:s:b:";

const struct option long_options[] = {

{ "help", 0, NULL, 'h'},

{ "device", 1, NULL, 'd'},

{ "string", 1, NULL, 's'},

{ "baudrate", 1, NULL, 'b'},

{ NULL, 0, NULL, 0 }

};

program_name = argv[0];

do {

next_option = getopt_long (argc, argv, short_options, long_options, NULL);

switch (next_option) {

case 'h':

print_usage (stdout, 0);

case 'd':

device = optarg;

havearg = 1;

break;

case 'b':

speed = atoi(optarg);

break;

case 's':

xmit = optarg;

havearg = 1;

break;

case -1:

if (havearg) break;

case '?':

print_usage (stderr, 1);

default:

abort ();

}

}while(next_option != -1);

sleep(1);

fd = OpenDev(device);

if (fd > 0) {

set_speed(fd, speed);

} else {

fprintf(stderr, "Error opening %s: %s
", device, strerror(errno));

exit(1);

}

if (set_Parity(fd,8,1,'N')== FALSE) {

fprintf(stderr, "Set Parity Error
");

close(fd);

exit(1);

}

pid = fork();

if (pid < 0) {

fprintf(stderr, "Error in fork!
");

} else if (pid == 0){

while(1) {

printf("%s SEND: %s id %d
",device, xmit,i);

write(fd, xmit, strlen(xmit));

sleep(1);

i++;

}

exit(0);

} else {

while(1) {

nread = read(fd, buff, sizeof(buff));

if (nread > 0) {

buff[nread] = '';

printf("%s RECV %d total
", device, nread);

printf("%s RECV: %s
", device, buff);

}

}

}

close(fd);

exit(0);

}

使用gcc命令进行编译，然后执行生成的可执行文件

列入：./serialtest -d /dev/ttyS* -b 115200
